Cleanroom Definition and Purpose

What is a cleanroom?

According to ISO 14644-1 standards, a cleanroom is defined as a controlled environment where the concentration of airborne particles is maintained at specified levels. These specialized spaces are designed and constructed to minimize the introduction, generation, and retention of particles inside the room, while also controlling other relevant parameters such as temperature, humidity, and pressure as necessary.

1. Cleanroom Fundamentals

A cleanroom is a highly controlled environment designed to maintain extremely low levels of airborne particles, contaminants, and pollutants. These specialized spaces are crucial for industries and research fields where even microscopic particles can interfere with sensitive processes or products. Cleanrooms are characterized by:

  • Strict control of air quality through advanced filtration systems (HEPA or ULPA filters)
  • Regulated environmental parameters such as temperature, humidity, and air pressure
  • Specialized construction materials and design to minimize particle generation
  • Rigorous protocols for personnel entry, including protective clothing and gowning procedures

Cleanrooms are widely used in industries such as semiconductor manufacturing, pharmaceuticals, biotechnology, medical device production, and aerospace. The level of cleanliness in a cleanroom is classified according to the number of particles per cubic meter of air, with classifications ranging from ISO Class 1 (most stringent) to ISO Class 9 (least stringent).

2. Cleanroom Classification Standards

Cleanroom classifications are standardized systems used to define the level of cleanliness in controlled environments. The two most widely recognized standards are ISO 14644-1 and Federal Standard 209E (now obsolete but still referenced). Here's a comparison of these classification systems:

 ISO 14644-1  Federal Standard 209E  Maximum particles ≥0.5μm per m³
 ISO 3  Class 1  1,000
 ISO 4  Class 10  10,000
 ISO 5  Class 100  100,000
 ISO 6  Class 1,000  1,000,000
 ISO 7  Class 10,000  10,000,000
 ISO 8  Class 100,000  100,000,000



ISO 14644-1 provides a more comprehensive range of classifications, including ISO 1 and 2 for extremely clean environments and ISO 9 for less stringent requirements.

The pharmaceutical industry often uses additional classifications based on EU GMP guidelines, which define Grades A, B, C, and D, corresponding to specific ISO classes in both "at rest" and "in operation" states.



Cleanroom Contamination Control

Cleanroom contamination control is crucial for maintaining the integrity of controlled environments. Key strategies include:

  • Implementing rigorous gowning protocols to minimize human-generated particles
  • Establishing regular cleaning schedules using cleanroom-specific products
  • Employing real-time particle monitoring systems for immediate contamination detection
  • Minimizing equipment and tools in the cleanroom, using only cleanroom-safe materials
  • Conducting routine maintenance on all equipment, including HVAC systems and filters
  • Training personnel as "contamination control ambassadors" to promote best practices
  • Utilizing rapid microbiological methods for faster detection of microbial contamination

Effective contamination control requires a comprehensive approach, combining facility design, personnel management, and ongoing monitoring to ensure cleanroom environments consistently meet their specified cleanliness standards.



Airflow and Filtration Techniques

Cleanrooms employ two primary airflow patterns to maintain particle-free environments: laminar (unidirectional) and turbulent (non-unidirectional) flow.

Laminar airflow moves in uniform, parallel layers, effectively sweeping particles downward and out of the cleanroom.

This technique is crucial for highly sensitive applications requiring ISO 5 or cleaner environments. Turbulent airflow, while less controlled, is suitable for less stringent cleanroom classifications and offers cost-effective particle dilutio.

Key components of cleanroom airflow systems include:

  • HEPA (High-Efficiency Particulate Air) or ULPA (Ultra-Low Particulate Air) filters for removing microscopic particles
  • Fan filter units (FFUs) to distribute filtered air evenly
  • Pressure differentials between rooms to prevent contamination
  • Air returns and plenums for efficient air recirculation
  • Automated control systems for maintaining consistent airflow and adjusting fan speeds as needed

Proper airflow design and management are essential for achieving and maintaining the required cleanliness levels in cleanroom environments.



Ambient Air Monitoring Techniques

Monitoring ambient air cleanliness involves using specialized equipment and techniques to measure various pollutants and particulate matter. Key methods include:

  • Continuous air quality monitors that provide real-time data on criteria pollutants like particulate matter (PM2.5, PM10), nitrogen dioxide, sulfur dioxide, carbon monoxide, and ozone
  • Sensor-based systems using technologies such as NDIR, electrochemical analysis, and laser-scattering to measure multiple parameters simultaneously
  • Open-path monitoring systems that measure average pollutant concentrations over extended paths using techniques like DOAS (Differential Optical Absorption Spectroscopy) or FTIR (Fourier Transform Infrared)
  • Mobile monitoring platforms, including vehicle-mounted instruments and drones, for assessing pollution in specific areas or from particular sources

Data from these monitoring systems is typically collected, analyzed, and reported to relevant authorities to assess compliance with air quality standards and inform pollution control strategies.

Regular calibration and quality assurance procedures are essential to ensure accurate and reliable measurements.
